DEVICECRAFT FITCHBURG, MA 01420 978 518 1183
|

1005-20A-50V datasheet
|
MOSFET H-Bridge Speed Controller Module on heat sink plate available with various firmware
|
50Volt 20Amps (11 to 50Vdc) Analog speed control Forward/Reverse, Over Current/Temperature protection
|
|
1005-20A-90V datasheet
|
MOSFET H-Bridge Speed Controller Module on heat sink plate available with various firmware
|
90V 20Amps (20 to 90Vdc) Analog speed control Forward/Reverse Over Current/Temperature protection
|
|
1005-10A-190V datasheet
|
MOSFET H-Bridge Speed Controller Module on heat sink plate available with various firmware
|
190V 10Amps (30 to 190Vdc) Analog speed control Forward/Reverse Over Current/Temperature protection
|
|
| |
|
|
|
1005-Direct datasheet
|
Optional Configuations
|
Standard Forward and Reverse speed control on one control line. Acceleration control, brake, coast control lines. Zero seconds direction change.
Alternate Forward/Reverse control line, speed control line, forward and reverse stop line. Regenerative slowing
Direct Control 1005 series controller MOSFETs Directly with MCU
Coil Optimized for bipolar coil driving.
Wave Generated waves from 20Hz to 400Hz. Sine Modified Sine, Triangle selection.
Torque Control maximum delivered torque/current along with maximum speed control. Custom.
PCM Accepts industry standard signals from RC receiver to control forward and reverse speed. Shuts off with no signal
|
Free
|
| |
|
|
|
1005-Custom
|
H-Bridge Controller
|
Custom Voltages, Currents, control please send brief specifications no charge for most small firmware changes
|
contact us!
|
1005-20A-50V 1005-10A-190V
|
|
Forward and Reverse control with one Pot and Ramp time control Enclosure with LED indicators Only Power Supply and Motor Hookup needed
|
$129 $139
|
1009-20A-50V 1009-20A-90V 1009-10A-190V
|
|
Small motor speed controller 2" x 2.6" Low Cost Only Samples available.
|
$69 $79 $89
|
1006-20A-50V 1006-20A-90V 1006-10A-190V
|
|
High current motor controller 100+ Amps other specifications same as 1005, plus on board acceleration potentiometer
3.6" x 2.6" Bar connectors (Bars Underdevelopment) Only Sample available
|
$200 $210 $220
|
|
DC Motor Speed Controllers
MOSFET H-Bridge Construction
High Power High Voltage
Applications:
Scooters, Robots, Reversible DC motor Control,
Custom PWM, Custom DC-DC converters, Large
Solenoid Driver, Windmills, Solar, Industrial,
Military, Sound, Hobby.
Fully assembled and tested
Same day Free shipping
for standard configurations
Quiet 18Khz PWM and Fast Hall
effect Short Circuit Protection
